Device Directory

Meters, sensors and controllers, and how each connects to Edge.

394 device pages · 121 manufacturers with device pages

398 devices

Device database results

398 devices

Develco MOSZB-140

Motion, temperature and light sensorZigbee

A battery-powered Zigbee PIR sensor that reports motion, room temperature and light level from one housing, with a 9 m detection range and two AA cells rated for three years. Edge reads it through the Gateway’s Zigbee radio.

  • Temperature and humidity
  • Occupancy

Develco ZHEMI101

External meter interfaceZigbee

A battery-powered Zigbee interface that reads an existing utility meter through an optical probe: the pulse LED on an electricity meter, or the IR port of meters that speak IEC 62056-21 or Kamstrup KMP. Edge reads it through the Gateway’s Zigbee radio.

  • Pulse and I/O

Manufacturer (opens in a new tab) (opens in a new tab)

Frient EMIZB-151

P1 smart meter interfaceZigbee

A Zigbee 3.0 reader that plugs into the P1 port of a DSMR 4.2 or 5.0.2 smart electricity meter and reports its imported and exported energy, tariff registers, power, voltage and current. Edge reads it through the Gateway’s Zigbee radio.

  • Pulse and I/O

Manufacturer (opens in a new tab) (opens in a new tab)

Frient SMRZB-342

DIN rail relay with meteringZigbee

A DIN rail relay that switches a 16 A circuit over Zigbee 3.0 and meters its voltage, current, power and energy to a typical ±1 %, with overload and over-temperature protection built in. Edge reads it through the Gateway’s Zigbee radio.

  • Smart plugs

Manufacturer (opens in a new tab) (opens in a new tab)

Heiman HS2TD

Door sensor with temperature and humidityZigbee

A battery-powered Zigbee door contact that also measures room temperature and relative humidity, with writable calibration offsets, derived comfort values and diagnostic counters in the same device. Edge reads it through the Gateway’s Zigbee radio.

  • Temperature and humidity

Heiman HS9MS-E

PIR motion sensor with cameraZigbee

A battery-powered Zigbee PIR motion sensor with a camera that sends pictures over Wi-Fi. Edge reads it through the Gateway’s Zigbee radio.

  • Occupancy

IKEA PARASOLL E2013

Door and window sensorZigbee

A magnetic contact for doors, windows and cabinets that runs on one rechargeable AAA cell, mounts in three orientations and can switch up to ten IKEA smart lights directly as well as report to Edge. Edge reads it through the Gateway’s Zigbee radio.

  • Occupancy

Manufacturer (opens in a new tab) (opens in a new tab)

Moes BRT-100-TRV

Thermostatic radiator valveZigbee

A battery-powered Zigbee radiator valve head for M30 × 1.5 valves, with a 5 to 45 °C setpoint, ±0.5 °C accuracy, open-window detection and a boost mode, running on two AA cells. Edge reads it through the Gateway’s Zigbee radio.

  • Heating controls

Manufacturer (opens in a new tab) (opens in a new tab)

NodOn SIN-4-1-21

Relay switch with meteringZigbee

A flush-mount Zigbee 3.0 relay for 230 V loads up to 14 A and 3000 W that meters instantaneous power and cumulative energy, and can also work as a potential-free contact for a boiler or a gate. Edge reads it through the Gateway’s Zigbee radio.

  • Smart plugs

Manufacturer (opens in a new tab) (opens in a new tab)

OWON CB432

DIN-rail relay with energy meteringZigbee

A Zigbee 3.0 DIN-rail relay in 32 A and 63 A versions that switches a single-phase circuit and meters its power and energy, to within ±2 W up to 100 W and ±2 % above. Edge reads it through the Gateway’s Zigbee radio.

  • Smart plugs

Manufacturer (opens in a new tab) (opens in a new tab)
