Huawei LUNA2000-241-2S1

Commercial and utility battery energy storage system

LUNA2000-241-2S1 combines 241 kWh of LFP storage with a 108 kW PCS, hybrid cooling, Ethernet or fibre and a named Modbus TCP interface. Edge reads it over Modbus TCP, directly or through a SmartLogger3000, using the project point map for the installed firmware.

Huawei LUNA2000-241-2S1
  • Modbus TCP
  • Ethernet

Commercial and utility battery energy storage system

Ask an engineer

Compatibility

Compatible with EpiSensor Edge over Modbus TCP

Huawei's datasheet names Modbus TCP over Ethernet or fibre, and Edge is a Modbus TCP client. Edge reads the cabinet on the site network, or the SmartLogger3000 that manages it over the SmartLogger's Modbus TCP interface. The read points come from the project's point map for the installed firmware.

LUNA2000-241-2S1, datasheet version 01-202601 and user manual issue 19. Site check: obtain the point map for the installed firmware and the endpoint in use, the ESS itself or the SmartLogger3000. Keep PCS2000-108K-MB1, pack optimisers, BMS, EMS, meters and project controller identities separate. Read-only monitoring; no control or safety authority is transferred.

Connect it with

Route into Edge

When the project exposes the cabinet’s own Modbus TCP endpoint to a monitoring client

  • Modbus
  • Edge
  • Platforms
Commercial and utility battery energy storage system
Interface
Gateway
Edge
Output
LUNA2000-241-2S1LUNA2000-241-2S1 Ethernet or fibre port
Protected EthernetSegmented LAN
ZGW-20 GatewayHosts Edge locally
EpiSensor EdgeModbus client + register map
Customer platformMQTT · API · files
Modbus TCP
Protected Ethernet
Runs locally
Optional onward data
Give Edge an address on the protected site network and configure the cabinet’s endpoint from the project point map. Start with identity, state, power and state of charge, and compare the first readings with the cabinet’s local view. Read only. The customer-platform output is optional; Edge remains the local system of record.

When the cabinet is managed by a SmartLogger3000

  • Wired
  • Edge
  • Platforms
Commercial and utility battery energy storage system
Interface
Gateway
Edge
Output
LUNA2000-241-2S1LUNA2000-241-2S1
Huawei SmartLogger3000Manages the ESS and serves plant data over Modbus TCP
ZGW-20 GatewayHosts Edge locally
EpiSensor EdgeModbus client + register map
Customer platformMQTT · API · files
Commissioned Huawei plant link
Ethernet, Modbus TCP
Runs locally
Optional onward data
Leave the cabinet on its SmartLogger. Connect Edge to the SmartLogger's Modbus TCP monitoring endpoint, as the SmartLogger3000A guide describes, and confirm the selected cabinet under Monitoring, ESS. Read only. The customer-platform output is optional; Edge remains the local system of record.

Models

Download
ModelsInterfaceRoute into Edge
LUNA2000-241-2S1241 kWh ESS with PCS2000-108K-MB1, Ethernet, fibre and Modbus TCPRead over Modbus TCP, directly or through the SmartLogger3000, with the project point map for the installed firmware.
LUNA2000-215-2S10Separate 215 kWh C&I model on the same support family pageUse its own datasheet and project interface contract; do not transfer 241-2S1 values.

Specifications

The January 2026 datasheet specifies 241.0 kWh, a 108 kW PCS and four 240S1P LFP packs in one LUNA2000-241-2S1 system.2

Stored energy
241.0 kWh maximum2
PCS
PCS2000-108K-MB1, 108 kW nominal output2
Battery
LFP, 314 Ah cells, four 240S1P packs2
Published communications
Ethernet, fibre and Modbus TCP2
Environment
IP55; -30 to +55 °C, derating above +50 °C; up to 4,000 m2
Safety scope
Fire, anti-islanding, insulation, residual-current and overcurrent functions remain with the commissioned system2

Interface

Documented measurements and integration boundaries for LUNA2000-241-2S1.

  • Potential identity, operating mode, state of charge, state of health, power, energy, temperatures and alarms require the approved project point map.
  • Pack optimiser, battery, PCS, EMS, site-meter and grid-meter values must retain their distinct sources and time bases.
  • Fire-system, anti-islanding, insulation, residual-current and overcurrent functions remain under the commissioned safety and protection design.
  • No power setpoint, charge, discharge, grid-forming, anti-backflow, black-start or protection command is approved by this guide.

Assessment

LUNA2000-241-2S1, datasheet version 01-202601. Edge reads it over Modbus TCP, directly or through the SmartLogger3000. Keep PCS2000-108K-MB1, pack optimisers, BMS, EMS, meters and project controller identities separate. No control or safety authority is transferred.

InteroperabilityLimited
The manufacturer names relevant communications, but the retained public evidence does not provide a complete firmware-matched, read-only third-party interface contract.12
AccuracyNot yet assessed
The public datasheet does not list the readable point set, units, sign conventions, quality states or freshness rules; they come from the project point map.12
SecurityNot yet assessed
Authentication, encryption, roles and read-only privilege separation for an independent client are not defined in the retained public sources.12
ReliabilityLimited
System operating limits are published; client recovery, stale-data behaviour and concurrent-client limits are set by the project configuration.12
RuggednessSupported with conditions
IP55, temperature, humidity and altitude limits are published; the installed site and fire design remain authoritative.12
ScalabilityLimited
The support family covers parallel systems, but external client count, polling and aggregation limits are not public.12
LifecycleSupported with conditions
A current January 2026 datasheet and support page exist; record firmware, warranty and service status for each project.12

Setup

  1. Confirm the delivered system

    Record every enclosure, battery rack, PCS, BMS, EMS, meter and controller identity, plus firmware, software, network and contract revisions.

  2. Map authority before data

    Document which system owns charge and discharge, protection, fire and life safety, grid control, market dispatch, settlement, warranty and emergency response.

  3. Obtain the interface contract

    Use user manual issue 19, section 9.4, to record the actual network arrangement. DHCP is enabled by default. For multiple cabinets using static addresses, configure each ESS consistently and record a unique address through the local app’s Communication settings and Wired Network Settings. Select the matching SmartLogger3000 or SmartLogger5000/SmartMGC5000 solution manual for the site topology.

  4. Prove read-only monitoring

    On SmartLogger3000, open Monitoring, ESS, Running Info and Basic Information to confirm the selected cabinet identity. Keep startup authorization with the commissioning provider: the manual requires a vendor or authorized service provider for the startup code. Compare the cabinet’s reported operating state and power with the site meter during a known interval; request the external read map for the chosen controller instead of tapping internal BCU or PCS links.

Common questions

Is the LUNA2000-241-2S1 compatible with Edge?
Yes, over Modbus TCP: Edge reads the cabinet or the SmartLogger3000 that manages it on the site network. The public datasheet does not publish addresses, types, units or permissions, so take those from the project point map for the installed firmware.2
Can the 215 kWh model use this guide?
No. LUNA2000-215-2S10 has a different capacity and battery configuration. Use its exact datasheet and project contract.1
Can Edge control anti-backflow or grid-forming operation?
No. Those functions depend on the project EMS, meters, protection and grid approval. This guide releases no write path.2
