GoodWe SDT G3 8–15 kW
Three-phase grid-tied PV inverter
GoodWe SDT G3 8–15 kW inverters are compatible with EpiSensor Edge over SunSpec-compliant Modbus RTU. Identify the inverter-network RS485 terminals, discover the returned models and compare decoded AC power with the local interface. Keep the separate export-control meter connection intact.
Compatibility
Compatible with EpiSensor Edge over Modbus RTU (SunSpec)
The exact-family V2.1 datasheet specifies SunSpec-compliant Modbus RTU, and the V2.4 manual puts the inverter-network RS485 on terminals 1–4. Edge reads it as a Modbus RTU client through a ZMB-31 Modbus Interface or the Gateway’s serial port, with SunSpec model discovery setting the point layout.
GW8000-SDT-30, GW10K-SDT-30, GW10K-SDT-EU30, GW12K-SDT-30 and GW15K-SDT-30, Model d terminals in manual V2.4. Site check: use the commissioned serial settings and address with Edge as the only client on the inverter-network pair, and keep the meter and export-control wiring on terminals 5/6.
Connect it with
When the B1/A1 inverter-network pair is free for one Modbus master, with no GoodWe logger or SEC controller on it
- Modbus
- Wireless
- Edge
- Platforms
Models
| Models | Interface | Route into Edge |
|---|---|---|
| GW8000-SDT-30 | 8 kW nominal AC, two MPPTs and one string per MPPT in the V2.1 sheet | Modbus RTU on Model d terminals 1/2 or 3/4; check the terminal drawing for the installed revision. |
| GW10K-SDT-30 and GW10K-SDT-EU30 | Both are 10 kW nominal AC, but the EU30's listed maximum active power is 10 kW versus 11 kW for the -30 | Do not collapse the regional EU30 variant into the -30 when sizing or applying a grid profile. |
| GW12K-SDT-30 and GW15K-SDT-30 | 12 and 15 kW nominal AC; two MPPTs, one string per MPPT | Check nameplate and national certificates before selecting the inverter or a communications accessory. |
| GW17K/20K/25K/30K SDT G3, LV, AU and BR variants | Other ratings and market versions outside this 8–15 kW guide | The broader product page and manual cover different current, string, cooling and terminal configurations; do not transfer this guide's variant assumptions. |
Specifications
The March 2026 sheet identifies the covered five codes in the 4–30 kW two-MPPT range. Each has 1100 V maximum DC input, 140–1000 V MPPT operating range, IP66 enclosure and nominal 220/380, 230/400 or 240/415 V three-phase output, subject to local grid standards.2
- Nominal AC power
- 8, 10, 10, 12 or 15 kW respectively2
- PV tracking
- Two MPPTs, one string per MPPT for the covered models2
- Inverter-network RS485
- Manual Model d: B1/A1 on terminals 1/2 and 3/4, for a logger or inverter network3
- Meter RS485
- Manual Model d: B2/A2 on terminals 5/6, for the export-control meter3
- Published protocols
- SunSpec-compliant Modbus RTU and Modbus TCP; discover the returned models on the commissioned endpoint2
- Enclosure and cooling
- IP66; natural convection in this 8–15 kW subset2
Interface
Documented measurements and integration boundaries for SDT G3 8–15 kW.
- The V2.4 manual groups all five covered models as Model d. Its RS485 B1/A1 terminals 1–4 connect inverter networks or a GoodWe data logger. Its separate meter B2/A2 terminals 5–6 support the meter and CT export-control arrangement. Trace the existing plant before connecting another client.
- The manual describes GoodWe collector options: EzLogger Pro or SEC1000 up to 20 inverters per COM port, EzLogger 3000C or SEC3000 up to 25. These are GoodWe bus design limits for its own collectors. The manual reserves SEC3000C for GW50K-SDT-C30, outside this group.
- The V2.1 datasheet specifies SunSpec-compliant Modbus RTU for this 8–15 kW subset, alongside Modbus TCP and optional communications hardware. Start with the inverter RS485 discovery procedure below. Check the fitted stick’s documentation separately when choosing a TCP connection.
- For export limiting or 24-hour consumption monitoring, the manual requires a correctly placed grid-point CT and meter. Inverter AC power alone cannot measure net import or export; verify CT direction, phase mapping and sign at the connection point.
- RCR inputs may serve grid dispatch requirements in Germany and remote shutdown is integrated, but the manual says those functions are disabled by default and require commissioning. A physical input is not an authorisation for third-party software dispatch.
Assessment
The five named -30/-EU30 models only; GoodWe's broader SDT G3, LV, AU and BR portfolio is excluded.
- InteroperabilitySupported with conditions
- The exact-family datasheet specifies SunSpec-compliant Modbus RTU, and the manual separates inverter and meter bus terminals. Public SunSpec discovery and model definitions give Edge its read procedure on the inverter-network pair.2345
- AccuracySupported with conditions
- SunSpec model 103 defines signed AC power and its scale factor when that model is returned. Compare decoded power with the local interface and check freshness on the installed unit.35
- SecurityNot yet assessed
- Read-only access and network controls depend on the selected GoodWe collector or stick and firmware.3
- ReliabilityNot yet assessed
- The manual does not describe polling cadence, stale data or reconnect behaviour; treat a timeout as unavailable data rather than zero.3
- RuggednessSupported with conditions
- IP66 and -30 to +60 °C are published, subject to siting, sealing and temperature derating.2
- ScalabilityLimited
- The manual gives 20 or 25 inverters per GoodWe collector COM port by collector type, but this is not an Edge fleet limit.3
Setup
-
Match the exact nameplate
Record the whole model suffix, country approval, inverter firmware and grid profile. The EU30 and ordinary 10 kW -30 have different published maximum AC output.
-
Trace the GoodWe communication topology
Identify the fitted logger, SEC controller or communications stick. For the five covered Model d units, terminals 1/2 and 3/4 are B1/A1 for inverter networking or a logger; terminals 5/6 are B2/A2 for the meter. Use the inverter-network pair for discovery, with the commissioned bus owner’s agreement.
-
Document the grid-point measurement
Record the meter, CT ratio, CT arrow, three phase mapping and physical point of connection. Compare GoodWe's load and export readings against an independent meter before treating them as site flexibility data.
-
Discover the SunSpec models
On an installer-approved inverter RS-485 bus, use the configured server address and serial settings with one client. FC03 reads two registers at wire addresses 0, 40000 or 50000 to find the SunSpec signature 53 75 6E 53. Read each model header (ID and length), advance by length + 2, and stop at ID 65535. Record the returned model IDs; do not assume model 103 or fixed positions.
-
Read AC power
If discovery returns model 103, let H be its header wire address. FC03 at H + 14, quantity 2, reads signed int16 W and W_SF. Power = W × 10^W_SF; 0x8000 means unavailable. Synthetic H = 40070 gives PDU 03 9C 94 00 02; bytes 30 39 FF FF mean 12345 × 10^-1 = 1234.5 W. Compare with GoodWe’s interface. Model 113 or another returned model needs its own definition.
-
Keep controls separate
Document who owns export limitation, RCR, remote shutdown and any VPP dispatch. Edge reads only; do not write setpoints or alter grid settings on the basis of a protocol label.
Common questions
- Does the Wi-Fi/LAN stick give Edge a direct Modbus TCP connection?
- The datasheet lists Modbus TCP and optional communication hardware, but the retained documents do not describe the service or point map of a particular stick. Connect Edge to the inverter-network RS485 pair over Modbus RTU instead; it carries the SunSpec models directly.23
- Can inverter output represent site export or VPP capacity?
- No. The manual's export-limit topology uses a meter and correctly oriented CTs near the grid connection point. Establish net site power, loads, controllability and dispatch permission separately.3
- Is the GW10K-SDT-EU30 identical to GW10K-SDT-30?
- Both are rated 10 kW nominal, but the V2.1 sheet lists 10 kW maximum AC active power for the EU30 and 11 kW for the -30. Use the exact suffix for sizing and local approval.2
- How can I make a first read without a GoodWe register map?
- Use the V2.1 datasheet and V2.4 manual as the starting revisions. Discover SunSpec on the inverter-network bus using its configured address and serial settings. If model 103 is returned, the setup procedure reads W and W_SF and compares the result with GoodWe’s interface. Use the definition of the model actually returned; model 113 has a different layout.2345
Sources
- GoodWe SDT G3 Series 4–30 kW product page and exact model list (opens in a new tab)
- SDT G3 Series 4–30 kW datasheet, 20260317-EN-V2.1 (opens in a new tab)
- SDT G3 Series user manual, V2.4, 25 March 2026 (opens in a new tab)
- SunSpec Device Information Model Specification v1.4 (opens in a new tab) (PDF)
- SunSpec three-phase inverter model 103 definition (opens in a new tab)
